Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Tray
Status Active
Type Transceiver
Protocol IEEE 1394
Number of Drivers/Receivers 6/6
Duplex Half
Supply Voltage - Operating 3 V to 3.6 V
Temperature Range - Operating 0°C to 70°C
Mounting SMD (SMT)
Case / Package 80-HTQFP (12x12)
Win Source Part Number 081822-TSB81BA3EPFP
Family Name TSB81BA3E
Introduction Date May 01, 2009
ECCN EAR99
Country of Origin Philippines
Halogen Free Compliant
Estimated EOL Date 2027
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian TSB81BA3EPFP CAD Model

Description

The TSB81BA3EPFP from Texas Instruments is a highly integrated 3-port cable transceiver/arbiter device designed for high-speed serial bus applications. This innovative component is compliant with the IEEE 1394b standard, making it ideal for applications requiring fast and reliable data transfer, such as digital audio/video networks, storage area networks, and industrial control systems.

Key Features and Benefits

  • High-Speed Data Transfer: The TSB81BA3EPFP supports S400 (400 Mbps) signaling rates, ensuring swift data transmission for time-sensitive applications.
  • IEEE 1394b Compliance: This device is fully compliant with the 1394b standard, providing compatibility with a wide range of devices and systems.
  • Three Cable Ports: With three bilingual cable ports, the device offers flexibility in connecting multiple devices in a daisy-chain or tree topology.
  • Cable Power Management: The integrated cable power management feature allows for efficient power distribution among connected devices, reducing overall power consumption.
  • Programmable Arbiter: The onboard programmable arbiter ensures fair access to the bus, enhancing system performance and data flow management.
  • Robustness: The TSB81BA3EPFP is designed to handle beta mode operation and can tolerate cable disconnections and hot-plugging without data loss or system interruption.
  • Package: Offered in a 64-pin HTQFP (Heat-Sink Thin Quad Flat Package), it provides a compact footprint and excellent thermal performance.
  • Industrial Temperature Range: The device operates over an extended temperature range of -40°C to 85°C, making it suitable for demanding industrial environments.

Applications

The TSB81BA3EPFP is versatile and can be used in various high-speed communication applications. Notable uses include:

  • Professional Audio/Video Equipment
  • Home Networking Systems
  • Mass Storage Systems
  • Automotive and Transportation Infotainment
  • Industrial Control and Instrumentation

With its high-speed capabilities and adherence to the IEEE 1394b standard, the TSB81BA3EPFP is an excellent choice for developers and manufacturers looking to incorporate reliable data transfer mechanisms into their systems. Texas Instruments' commitment to quality ensures that this device will provide a robust and efficient solution for a multitude of serial bus applications.
