The TPS54335ADRCR is a versatile and efficient DC/DC converter solution from Texas Instruments, designed to cater to a wide array of power management requirements. This advanced step-down converter is capable of delivering up to 3A of continuous output current with an input voltage range of 4.5V to 28V, making it an excellent choice for various applications in consumer electronics, industrial systems, and automotive products.

Key Features

• Output Voltage Range: The TPS54335ADRCR provides an adjustable output voltage range from 0.8V to as high as 25V, which can be set using external resistors. This flexibility allows it to be used in systems requiring different voltage levels.
• High Efficiency: With its integrated 80mΩ high-side MOSFET, the converter achieves high efficiency at light loads with a pulse skipping Eco-mode™, which significantly reduces the quiescent current.
• Thermal and Overcurrent Protection: The device includes cycle-by-cycle current limiting and thermal shutdown for enhanced safety and reliability under abnormal operating conditions.
• Stability: TPS54335ADRCR is stable with low equivalent series resistance (ESR) output capacitors, including ceramic types, which are common in modern electronic devices due to their small size and reliability.

Applications

The TPS54335ADRCR is suitable for a variety of applications, including:

• Consumer Electronics: Laptops, TVs, power supplies, and other portable devices.
• Industrial and Automation: Power regulators, sensors, and control systems.
• Automotive Applications: Infotainment systems, GPS, and other in-vehicle electronics.

Package and Quality

This component comes in a small, thermally enhanced 10-pin VSON package, ensuring a compact footprint while maintaining good thermal performance. The TPS54335ADRCR is also supported by Texas Instruments' commitment to quality and reliability, adhering to stringent industry standards for production and testing.

Design Resources

Designers can access a host of support materials provided by Texas Instruments, including datasheets, reference designs, and evaluation modules, to facilitate the integration of the TPS54335ADRCR into their projects.
