Products specifications

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Hot Swap Controller
Number of Channels 1
Internal Switch(s) Yes
Applications General Purpose
Features Latched Fault, OVP, Thermal Limit
Programmable Features Current Limit, Slew Rate, UVLO
Supply Voltage - Operating 4.5 V to 18 V
Current - Output (Max) 5A
Temperature Range - Operating -40°C to 85°C
Operating Supply Current 420μA
Mounting SMD (SMT)
Case / Package 10-VSON (3x3)
Feature Pins EN
Win Source Part Number 1111543-TPS259270DRCT
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian TPS259270DRCT CAD Model

Description

The TPS259270DRCT from Texas Instruments is a highly sophisticated circuit protection device designed to ensure the safety and reliability of various electronic systems. This component is part of the eFuse or current limiter product family, which is instrumental in providing overcurrent protection by limiting the amount of current that can pass through an electronic circuit, thus preventing damage to sensitive components.

Housed in a compact 3.00 mm x 3.00 mm, 10-pin VSON package, the TPS259270DRCT is engineered for space-constrained applications. It provides a continuous current of up to 5.5 A, making it suitable for a wide range of uses, from industrial to consumer electronics. The device operates over a wide input voltage range from 2.7 V to 18 V, accommodating various power requirements and ensuring versatility across different platforms.

One of the key features of the TPS259270DRCT is its integrated back-to-back FETs, which offer reverse current blocking capabilities. This is particularly useful for preventing damage from power supply faults or incorrect power sequencing. Additionally, the device includes an adjustable current limit, which allows for precise control over the maximum current provided to the load, further enhancing the protection capabilities.

The TPS259270DRCT also boasts a fast overcurrent response time, which is crucial for protecting electronic components from sudden surges in current. It has an operating temperature range of -40°C to 125°C, ensuring reliable performance under extreme conditions. Other features include under-voltage lockout, overvoltage protection, thermal shutdown, and an auto-retry feature that attempts to re-enable the device after a fault condition has been cleared.

In summary, the TPS259270DRCT from Texas Instruments is a robust, feature-rich circuit protection solution that offers a high level of performance and reliability. Its compact size, wide operating voltage range, and comprehensive protection features make it an ideal choice for designers looking to safeguard their electronic systems against a variety of electrical threats.
