The TMUX1247DCKR is a state-of-the-art precision analog multiplexer from Texas Instruments, designed to provide exceptional performance in a wide array of electronic applications. This advanced switch is part of TI's extensive multiplexer and signal switch portfolio, renowned for its reliability and versatility.

Key Features

• High Channel Count: The TMUX1247DCKR offers a 4-channel, 2:1 multiplexer configuration, allowing users to select between multiple input signals and route them to a single output, enhancing design flexibility and conserving board space.
• Low On-Resistance: This device boasts ultra-low on-resistance (Ron), minimizing signal distortion and ensuring high signal integrity, which is vital for precision applications.
• Wide Operating Voltage Range: It operates over a broad supply voltage range, compatible with various systems and ensuring easy integration into both digital and analog signal environments.
• Break-Before-Make Switching: The TMUX1247DCKR features break-before-make (BBM) switching, which prevents signal overlap during channel transitions and protects against shorting and current spikes.
• ESD Protection: The device is equipped with robust electrostatic discharge (ESD) protection, safeguarding the multiplexer against the damaging effects of static electricity and enhancing its durability.

Applications

The TMUX1247DCKR is ideal for a variety of applications, including but not limited to:

• Data acquisition systems
• Test and measurement equipment
• Signal routing in audio, video, and other multimedia systems
• Medical equipment
• Communication systems

Quality and Reliability

As with all Texas Instruments products, the TMUX1247DCKR is manufactured to the highest quality standards. Its robust design ensures reliable operation even in harsh industrial environments. Engineers can trust in the TMUX1247DCKR to deliver consistent performance and extend the lifespan of their electronic products.

Package and Availability

The TMUX1247DCKR comes in a compact SC70 package, optimizing board space without compromising on functionality. This product is available for order and can be sourced directly from Texas Instruments or authorized distributors.
