TLV6710DDCR

Part No TLV6710DDCR
Manufacturer Texas Instruments
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description WIDE SUPPLY COMPARATOR / Comparator Window Open Drain SOT-23-THIN
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs)>Linear - Comparators
Mfr Texas Instruments
Package Tape & Reel
Type Window
Number of Elements 2
Output Type Open Drain
Voltage - Supply, Single/Dual (±) 1.8V ~ 36V
Current - Input Bias (Max) 0.025µA
Current - Quiescent (Max) 11µA
Propagation Delay (Max) 9.9µs
Hysteresis 12mV
Temperature Range - Operating -40°C ~ 125°C
Package / Case SOT-23-6 Thin, TSOT-23-6
Mounting SMD (SMT)
Supplier Device Package SOT-23-THIN
Base Product Number TLV6710
MSL Level 2 (1 Year)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
Other Names 296-51698-6,TLV6710DDCR-ND,296-51698-2,296-51698-1
Standard Package 3,000
Win Source Part Number 1125059-TLV6710DDCR
Ultra Librarian 3D Model Ultra Librarian TLV6710DDCR CAD Model

Description

The TLV6710DDCR is a precision window comparator that integrates two comparators and a reference in a single package, designed and manufactured by Texas Instruments. This high-quality electronic component is tailored for voltage monitoring applications where precision is crucial. Its compact form factor, the SOT-23 package, makes it an excellent choice for space-constrained applications.

Key Features

  • Adjustable Thresholds: The device offers adjustable thresholds for both comparators, enabling precise monitoring of both overvoltage and undervoltage conditions.
  • Integrated Reference: Comes with an integrated 400-mV reference which provides tight accuracy and reduces the need for external components.
  • Low Quiescent Current: The TLV6710DDCR boasts a low quiescent current, making it suitable for battery-powered and low-power applications.
  • Wide Supply Voltage Range: It operates over a wide supply voltage range from 1.8 V to 18 V, accommodating a variety of power systems.
  • Open-Drain Outputs: Features open-drain outputs that allow for easy interfacing with other logic levels and the ability to wire OR multiple devices.
  • Temperature Range: The device is operational over an extended temperature range, making it reliable in diverse environmental conditions.

Applications

The TLV6710DDCR is versatile and can be used in numerous applications, including:

  • Battery chargers and management systems
  • Power supply monitoring
  • Industrial equipment sensors and monitors
  • Automotive systems
  • Portable and handheld electronics

Product Specifications

Parameter Value
Package Type SOT-23
Number of Channels 2
Output Type Open-Drain
Supply Voltage Range 1.8 V to 18 V
Operating Temperature Range -40°C to +125°C

With its precision monitoring capabilities, the TLV6710DDCR from Texas Instruments stands out as an essential component for designers looking to ensure system stability and safety through accurate voltage detection.
