Overview of Texas Instruments TLV431CDBZR

The Texas Instruments TLV431CDBZR is a precision low-voltage shunt voltage reference that offers the ease of use and flexibility of an adjustable shunt regulator with the precision voltage reference capability of a bandgap-based reference. It is a versatile component suitable for a wide range of applications, including power supplies, battery-operated devices, and precision voltage regulation systems.

Key Features

• Adjustable Output Voltage: The TLV431CDBZR can be programmed from the reference voltage of 1.24V up to 16V with two external resistors, providing a highly flexible solution for various design requirements.
• Low Voltage Operation: It operates at a minimum cathode voltage of 1.24V, which is ideal for low-voltage applications and enables better power efficiency.
• High Accuracy: The device offers a typical temperature coefficient of only 50ppm/°C, ensuring a stable output voltage over a wide temperature range.
• Low Dynamic Output Impedance: The low output impedance of the TLV431CDBZR allows for stable voltage regulation against load variations.
• Stable with Capacitive Loads: It is designed to be stable with capacitive loads, making it highly reliable in complex circuits.

Package and Availability

The TLV431CDBZR comes in a small SOT-23 (DBZ) package, making it ideal for space-constrained applications. Its small form factor is particularly beneficial for portable and compact electronic devices.

Applications

• Adjustable voltage and current sources
• Power supplies for consumer electronics
• Battery chargers and management systems
• Precision voltage regulators
• Portable and battery-powered equipment

Conclusion

With its combination of precision, flexibility, and low power operation, the Texas Instruments TLV431CDBZR is an excellent choice for designers looking to improve the performance and reliability of their power management systems. Its ability to operate over a broad voltage range and maintain stability under varying conditions makes it a versatile component for a multitude of electronic applications.
