Overview of TLC272IDR from Texas Instruments

The TLC272IDR is a high-performance, dual operational amplifier (op-amp) integrated circuit (IC) produced by Texas Instruments (TI), a leader in semiconductor design and manufacturing. This op-amp is part of the LinCMOS™ family and is designed to offer a wide range of features suitable for a variety of applications including instrumentation, sensors, and active filtering systems.

Key Features

• Low Power Consumption: The TLC272IDR is optimized for low power consumption, making it ideal for battery-powered and portable applications where power efficiency is critical.
• High Input Impedance: The device boasts a high level of input impedance, which minimizes the current draw from the input source and preserves signal integrity.
• Wide Supply Range: It operates over a wide supply range of ±1.35V to ±8V (or 2.7V to 16V single supply), offering flexibility in various power environments.
• Output Drive Capability: The op-amp can drive loads as low as 2kΩ in parallel with 100pF, which allows it to handle a wide range of load conditions.
• Low Noise: With its low noise characteristics, the TLC272IDR is suitable for applications requiring low noise and high fidelity signal amplification.

Applications

The TLC272IDR is versatile and can be used in numerous applications. It is particularly well-suited for:

• Active filters
• General purpose signal conditioning
• Data acquisition systems
• Power supply control
• Audio applications
• Medical instrumentation

Package and Quality

This op-amp comes in an 8-pin SOIC package, which is compact and suitable for space-constrained applications. The "IDR" suffix indicates that this version of the TLC272 is offered in a commercial temperature range and is available in tape and reel packaging for automated assembly processes. Texas Instruments ensures high-quality standards, and the TLC272IDR is no exception, meeting stringent quality control measures for reliable and consistent performance.
