SN74HC273PWRG4 Octal D-Type Flip-Flops with Clear

The SN74HC273PWRG4 from Texas Instruments is a high-performance, octal D-type flip-flop integrated circuit designed for use in a wide range of digital applications. This device features eight D-type flip-flops with direct clear inputs, making it ideal for use in buffer/storage registers, shift registers, and pattern generators.

Each flip-flop is equipped with a 3-state output, which can be used in bus-oriented systems. The 3-state outputs can drive bus lines or buffer memory address registers, contributing to the versatility of the SN74HC273PWRG4 in complex digital systems. The device operates at a voltage range of 2V to 6V, providing compatibility with standard TTL logic levels while also supporting the lower voltage requirements of modern digital electronics.

With its wide operating temperature range, the SN74HC273PWRG4 ensures reliable performance in various environmental conditions, making it suitable for industrial and commercial applications. The device is available in a TSSOP (Thin Shrink Small Outline Package) with 20 pins, which offers a compact footprint for space-constrained applications.

Key features of the SN74HC273PWRG4 include:

• Logic Type: D-Type Flip-Flop
• Number of Circuits: 8
• Output Type: 3-State
• Voltage - Supply: 2V to 6V
• Operating Temperature: -40°C to 85°C
• Mounting Type: Surface Mount
• Package / Case: TSSOP-20

Whether you're designing a microprocessor system or a timing circuit, the SN74HC273PWRG4 provides the reliability and functionality needed for your digital logic applications. Its clear function allows for the synchronous reset of outputs, which is essential for timing and control applications that require precise manipulation of signal states.

Manufactured by Texas Instruments, a leader in semiconductor solutions, the SN74HC273PWRG4 is designed to meet the rigorous standards of the electronics industry, ensuring high-quality performance and durability for your projects.
