The SN74HC244PWRE4 is an advanced high-speed CMOS octal buffer/line driver designed to be used in 3-state memory address drivers, clock drivers, and bus-oriented receivers and transmitters. Manufactured by Texas Instruments, this integrated circuit ensures reliable and efficient performance in a wide range of digital applications.

Key Features

• Wide Operating Voltage Range: The device operates on a wide voltage range from 2V to 6V, making it versatile for various digital logic levels and compatible with TTL (Transistor-Transistor Logic).
• High Current Drive: This product boasts a high current drive of ±6 mA at the outputs, which allows for driving high capacitive loads with ease.
• Low Power Consumption: It is designed for low power consumption, with a typical ICC of only 80 µA, making it suitable for battery-powered and energy-efficient applications.
• 3-State Outputs: The octal buffer/line driver features 3-state outputs which can be used in bus-oriented systems. The outputs can be placed in a high-impedance state, effectively disconnecting them from the bus.

Technical Specifications

Applications

The SN74HC244PWRE4 is ideal for a range of applications that require high-speed, high-drive, and 3-state outputs. It is commonly used in:

• Memory address drivers
• Clock drivers
• Bus-oriented interfaces
• Data transmission systems

With its robust design and comprehensive features, the SN74HC244PWRE4 from Texas Instruments is a reliable choice for designers looking to implement an efficient buffering solution in their digital systems.
