SN74HC04NSR

Name: SN74HC04NSR
Brand: Texas Instruments
SKU: 333426
Availability: InStock
Rating: 4.85 (48 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	SN74HC04NSR
Manufacturer	Texas Instruments
Catalog	Logic - Gates and Inverters
Description	IC HEX INVERTER 14SO
Datasheet	SN74HC04NSR Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Integrated Circuits
Manufacturer	Texas Instruments
Packaging	Reel - TR
Status	Active
Logic Type	Inverter
Number of Circuits	6
Number of Inputs	6
Supply Voltage - Operating	2 V to 6 V
Current - Quiescent (Max)	2μA
Current - Output High, Low	5.2mA, 5.2mA
Logic Level - Low	0.5 V to 1.8 V
Logic Level - High	1.5 V to 4.2 V
Max Propagation Delay @ V, Max CL	16ns @ 6V, 50pF
Temperature Range - Operating	-40°C to 85°C
Mounting	SMD (SMT)
Case / Package	14-SOP
Dimension	14-SOIC (0.209", 5.30mm Width)
Win Source Part Number	030106-SN74HC04NSR
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Application Field	Used in Consumer Electronics, Communications & Networking, Metering
Ultra Librarian 3D Model	Ultra Librarian SN74HC04NSR CAD Model

Alternative Products

Description

The SN74HC04NSR from Texas Instruments is a high-performance, advanced logic inverter that features six independent inverters.

Series: 74HC04
Operating Voltage Range: 2 to 6 volts
Input Levels: Accepts TTL input levels
Output Levels: Provides CMOS output levels
Noise Immunity: High
Technology: CMOS
Maximum Frequency: 25 MHz @ 5V
Power Dissipation: Low
Quiescent Current: Maximum 2µA @ 25°C
Package: 14-pin SO
Mounting: Surface-mount
RoHS Compliant: Yes
