The SN74AUP1T86DCKR is a high-performance, single-bit, dual-supply voltage level translator with three-state outputs from Texas Instruments. This device is designed to address the need for translating signals between different voltage domains in modern mixed-voltage digital systems. It is particularly suitable for applications where space is at a premium, thanks to its small form factor SC70 package.

Key Features

• Wide Voltage Range: The SN74AUP1T86DCKR operates at a wide range of supply voltages from 0.8V to 3.6V on the A side and 1.2V to 3.6V on the B side, making it versatile for interfacing between low-voltage and higher-voltage logic circuits.
• Low Power Consumption: With ultra-low power consumption, this level translator is optimized for use in power-sensitive applications, such as battery-operated devices.
• High-Speed Operation: It supports high-speed signal processing, which is essential for maintaining signal integrity in fast digital systems.
• Logic Level Translation: It provides bidirectional translation between high-logic-level and low-logic-level signals without the need for a direction control signal.
• ESD Protection: The device includes robust electrostatic discharge (ESD) protection, ensuring reliability and longevity in challenging electrical environments.
• Three-State Outputs: The three-state outputs allow for connection to a bus or other shared signal lines, providing additional flexibility in circuit design.

Applications

The SN74AUP1T86DCKR is ideal for a range of applications where voltage level translation is required, including:

• Mobile Phones
• Tablets
• Personal Electronics
• IoT Devices
• Computing
• Data Communication

Package and Quality

Encased in a compact 6-pin SC70 package, the SN74AUP1T86DCKR is designed to occupy minimal board space while delivering the high performance expected of Texas Instruments products. The device is also supported by Texas Instruments' commitment to quality and reliability, ensuring that it meets the rigorous standards required by the electronics industry.
