The SN74ACT2235-60FN is a high-performance, octal bidirectional transceiver from Texas Instruments, designed to facilitate the transfer of data between two buses of differing voltage levels. This integrated circuit is a part of the ACT family, renowned for its advanced CMOS logic, which operates with speed and efficiency while maintaining low power consumption.

Key Features

• Logic Type: Octal Bidirectional Transceiver
• Package / Case: PLCC-28
• Operating Temperature: -40°C to 85°C
• Logic Level - High: 2 V
• Logic Level - Low: 0.8 V
• Max Propagation Delay @ V, Max CL: 11ns @ 5V, 50pF
• Mounting Type: Surface Mount
• RoHS: Compliant

Performance and Applications

The SN74ACT2235-60FN offers an impressive propagation delay of 11ns, ensuring rapid data transfer between high-speed buses. The device operates over a wide voltage range and provides the necessary level shifting required for interfacing between 5V and 3.3V systems. This makes it ideal for use in mixed-voltage environments commonly found in telecommunications, computing, and industrial applications.

With its robust operating temperature range of -40°C to 85°C, the SN74ACT2235-60FN is suitable for use in demanding conditions, ensuring reliable performance regardless of the thermal challenges it may face.

Design and Quality

The SN74ACT2235-60FN is packaged in a 28-pin PLCC (Plastic Leaded Chip Carrier) format, which is favored for its compact footprint and durability. Texas Instruments' commitment to quality means that this transceiver meets or exceeds industry standards for performance and reliability. Additionally, the device is RoHS compliant, adhering to the latest environmental regulations that restrict the use of hazardous substances in electronic equipment.

Whether you are designing a new system or upgrading an existing one, the SN74ACT2235-60FN from Texas Instruments is an excellent choice for ensuring seamless data communication across different voltage domains.
