SN74AC244DBR Octal Buffer/Line Driver from Texas Instruments

The SN74AC244DBR is a high-performance, octal buffer and line driver designed to provide interface buffering for a wide range of applications. Manufactured by Texas Instruments, a leader in semiconductor solutions, this integrated circuit is part of the 'AC series and is crafted to deliver exceptional drive capability, speed, and signal integrity.

Featuring eight non-inverting buffers and line drivers with 3-state outputs, the SN74AC244DBR is ideal for driving bus lines or buffer memory address registers. The 3-state outputs ensure that multiple units can be connected to the same bus, allowing for bus line control in a shared environment without the risk of contention or data corruption.

Key Features:

• Logic Type: Octal Buffer/Line Driver, Non-Inverting
• Output Type: 3-State
• Number of Channels: 8
• Supply Voltage: 2 V to 6 V
• Operating Temperature Range: -40°C to 85°C
• Package / Case: SSOP-20
• Mounting Type: Surface Mount

The device is characterized for operation from -40°C to 85°C, ensuring reliable performance across diverse environmental conditions. The SN74AC244DBR operates at a supply voltage range from 2 V to 6 V, providing the flexibility to work with various logic levels and interfacing with both CMOS and TTL logic families.

The SN74AC244DBR comes in a space-saving SSOP-20 (Shrink Small Outline Package) that is suitable for surface-mounted technology (SMT), which is beneficial for compact PCB layouts and high-density electronic assemblies. This package type aids in efficient heat dissipation and provides a small footprint on the circuit board.

This product is widely used in data transmission systems, computer motherboards, and other digital applications where high-speed, reliable buffering and line driving are critical. With its robust design and proven reliability, the SN74AC244DBR from Texas Instruments is a trusted choice for engineers and designers looking to enhance their digital systems.

For detailed specifications, application notes, and additional resources, please refer to the official Texas Instruments product page for the SN74AC244DBR.
