Product Overview: SN74AC04PW by Texas Instruments

The SN74AC04PW, manufactured by Texas Instruments, is a high-speed, hex inverter integrated circuit that belongs to the 74AC series. This device is designed to perform the logical inversion function, which is essential in various digital circuits. The "hex" designation indicates that the chip contains six independent inverter gates, making it a versatile component for implementing multiple inverter functions on a single chip.

Key Features:

• Logic Type: Inverter
• Number of Circuits: Six independent inverters
• Supply Voltage Range: 2 V to 6 V, accommodating a wide range of applications and compatibility with TTL (Transistor-Transistor Logic) levels.
• Output Current: Capable of driving up to 24 mA, ensuring sufficient current for driving other logic inputs or LEDs.
• Propagation Delay Time: Fast switching times, typically 8 ns at 5 V, making it suitable for high-speed applications.
• Operating Temperature: -40°C to 85°C, offering reliable performance across a wide range of environmental conditions.
• Package / Case: 14-TSSOP, providing a compact form factor suitable for space-constrained applications.

Applications:

The SN74AC04PW is a versatile component that can be used in a wide array of electronic systems. Some common applications include:

• Waveform generation
• Signal conditioning
• Logic level shifting
• Oscillator circuits
• Pulse shaping
• Glitch elimination

Quality and Reliability:

Texas Instruments is known for its commitment to quality and reliability. The SN74AC04PW is no exception, meeting high standards of performance and durability. This product is RoHS compliant, ensuring adherence to environmental standards by restricting the use of certain hazardous substances in electrical and electronic equipment.

Ordering Information:

When ordering the SN74AC04PW, it can be sourced directly from Texas Instruments or through authorized distributors. The product is available in tube or tape and reel packaging, facilitating ease of integration into manufacturing processes.
