SN65LVDS32DRG4 Real Image SN65LVDS32DRG4 real image
Same model may have multiple batches, images only for reference.
SN65LVDS32DRG4 Real Image SN65LVDS32DRG4 real image
SN65LVDS32DRG4 Real Image SN65LVDS32DRG4 real image
Same model may have multiple batches, images only for reference.

SN65LVDS32DRG4

Part No SN65LVDS32DRG4
Manufacturer Texas Instruments
Catalog Interface - Drivers, Receivers, Transceivers
Description IC DIFF RECEIVER H-S 16-SOIC
Datasheet
SN65LVDS32DRG4 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Receiver
Protocol LVDS
Number of Drivers/Receivers 0/4
Receiver Hysteresis 50mV
Data Rate 400Mbps
Supply Voltage - Operating 3 V to 3.6 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 16-SOIC
Win Source Part Number 330846-SN65LVDS32DRG4
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian SN65LVDS32DRG4 CAD Model

Description

The SN65LVDS32DRG4 is a high-tech product from the globally renowned technology company, Texas Instruments.

  • Category: differential line receivers
  • Part of: company's broad portfolio of interface ICs
  • Technology: low-voltage differential signaling (LVDS)
  • Supply Voltage: 3.3V
  • Data Transmission Rate: up to 400 Mbps
  • Operating Temperature Range: from -40°C to 85°C
  • Fail-safe feature: guarantees a logic-high output when the input is left open, shorted, or terminated but undriven
  • Package: SOIC (D)
  • RoHS compliant: Yes
