SN65176BDR Texas Instruments
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Transceiver
Protocol RS422, RS485
Number of Drivers/Receivers 1/1
Duplex Half
Receiver Hysteresis 50mV
Supply Voltage - Operating 4.75 V to 5.25 V
Temperature Range - Operating -40°C to 105°C
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 006358-SN65176BDR
Family Name SN65176B
Introduction Date August 01, 2003
ECCN EAR99
Country of Origin Mexico
Halogen Free Compliant
Estimated EOL Date 2027
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian SN65176BDR CAD Model

Description

The SN65176BDR is a high-quality, reliable product manufactured by Texas Instruments, a globally recognized leader in the electronics industry.

  • Type: Differential bus transceiver
  • Application: Bidirectional data communication on multipoint bus transmission lines
  • Compatibility: TIA/EIA-485 and TIA/EIA-422
  • Operating Temperature: -40°C to 85°C
  • Feature: Wide common-mode voltage range
  • Protection: Thermal shutdown protection
  • Feature: High impedance, allowing up to 32 transceivers on the bus
  • Quiescent Power: Low, 300µA
  • Maximum Data Rate: 5 Mbps
  • Supply Voltage Range: 4.75 V to 5.25 V
  • Package: Small size SOIC (Small Outline Integrated Circuit)
  • Compliance: RoHS compliant
