REF1112AIDBZR Real Image REF1112AIDBZR Real Image1 REF1112AIDBZR Real Image2
Same model may have multiple batches, images only for reference.
REF1112AIDBZR Real Image REF1112AIDBZR Real Image1 REF1112AIDBZR Real Image2
REF1112AIDBZR Real Image REF1112AIDBZR Real Image1 REF1112AIDBZR Real Image2
Same model may have multiple batches, images only for reference.

REF1112AIDBZR

Part No REF1112AIDBZR
Manufacturer Texas Instruments
Catalog PMIC - Voltage Reference
Description IC VREF SHUNT 1.25V SOT23-3
Datasheet
REF1112AIDBZR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Reference Type Shunt
Output Type Fixed
Nominal Output Voltage (Min/Fixed) 1.25V
Output Current 5mA
Tolerance ±0.2%
Temperature Coefficient 15ppm/°C Typical
Noise - 0.1Hz to 10Hz 25μVp-p
Current - Cathode 1.2μA
Temperature Range - Operating -40°C to 125°C (TA)
Mounting SMD (SMT)
Case / Package SOT-23-3
Win Source Part Number 082104-REF1112AIDBZR
Family Name REF1112
Introduction Date January 14, 2004
ECCN EAR99
Country of Origin Thailand
Halogen Free Compliant
Estimated EOL Date 2028
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian REF1112AIDBZR CAD Model

Description

The REF1112AIDBZR from Texas Instruments is a high-performance, low power, fixed output, micropower voltage reference.

  • Output Voltage: 1.25V.
  • Initial Accuracy: 0.2%.
  • Quiescent Current: 100μA.
  • Package: Compact SOT-23-3.
  • Operating Temperature Range: -40°C to +125°C.
