Same model may have multiple batches, images only for reference.
PTN04050CAZT Texas Instruments – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

PTN04050CAZT

Part No PTN04050CAZT
Manufacturer Texas Instruments
Catalog DC DC Converters
Description DC DC CONVERTER 5-15V 12W
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Type Non-Isolated PoL Module
Number of Outputs 1
Voltage - Input (Min) 2.95V
Voltage - Input (Max) 5.5V
Voltage - Output 1 5 ~ 15V
Current - Output (Max) 2.4A
Applications ITE (Commercial)
Features OTP
Temperature Range - Operating -40°C ~ 85°C
Efficiency 90%
Mounting Type Surface Mount
Case / Package 4-SMD Module
Size / Dimension 0.87" L x 0.50" W x 0.36" H (22.1mm x 12.7mm x 9.1mm)
Package Tape & Reel (TR);Cut Tape (CT);Reel;Bulk
Supply and Demand Status Shortage
Win Source Part Number 1538735-PTN04050CAZT
Ultra Librarian 3D Model Ultra Librarian PTN04050CAZT CAD Model
