Product Overview: Texas Instruments PTH08T255WAD

The Texas Instruments PTH08T255WAD is a high-performance, non-isolated module with an adjustable output voltage, designed to meet the needs of a variety of applications. This power module is part of the PowerTrain™ family and offers a remarkable blend of features that make it suitable for high-density power systems that require a small footprint and efficient power conversion.

Key Features

• Wide Input Voltage Range: The PTH08T255WAD is capable of operating with an input voltage range from 4.5V to 14V, making it versatile for various system voltages.
• Adjustable Output Voltage: Its output voltage can be adjusted from 0.69V to 5.5V, allowing for a high degree of flexibility in powering different circuit components.
• High Efficiency: The module boasts an efficiency of up to 96%, ensuring minimal power loss and heat generation within electronic systems.
• Integrated Inductor: It features an integrated inductor, which helps in reducing the design complexity and external component count.
• Thermal Performance: The PTH08T255WAD is designed to offer excellent thermal performance, which is critical for maintaining reliability and longevity in electronic systems.
• Pre-Biased Startup: The module supports pre-biased startup, ensuring safe ramp-up of the system voltage.

Applications

The PTH08T255WAD is ideal for a range of applications, including but not limited to:

• Telecommunications infrastructure
• Networking equipment
• Servers and storage systems
• Industrial applications
• Test and measurement equipment

Quality and Reliability

As with all Texas Instruments products, the PTH08T255WAD is manufactured to high standards of quality and reliability. It is suitable for use in systems where consistent performance and durability are required.

Design Support

Designers can take advantage of Texas Instruments' extensive support ecosystem, which includes technical documentation, reference designs, and simulation tools to expedite the design process and achieve a shorter time-to-market.

The PTH08T255WAD power module from Texas Instruments is a comprehensive solution for power management, providing efficiency, flexibility, and reliability in a compact package, making it an excellent choice for a wide array of power supply applications.
