PTH05020WAH

Name: PTH05020WAH
Brand: Texas Instruments
SKU: 283821
Availability: InStock
Rating: 4.93 (5 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	PTH05020WAH
Manufacturer	Texas Instruments
Catalog	Power Supplies Board Mount DCDC Converters
Description	MODULE PIP .8-3.6V 22A T/H 10DIP
Datasheet	PTH05020WAH Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Power Supplies - Board Mount
Family	DC DC Converters
Manufacturer	Texas Instruments
Series	PTH05020W
Packaging	Tray
Type	Non-Isolated PoL Module
Number of Outputs	1
Voltage - Input (Min)	4.5V
Voltage - Input (Max)	5.5V
Voltage - Output 1	0.8 ~ 3.6 V
Current - Output (Max)	22A
Applications	ITE (Commercial)
Features	UVLO
Mounting Style	Through Hole
Package	10-DIP Module
Size / Dimension	1.50" L x 0.87" W x 0.35" H (38.1mm x 22.1mm x 8.9mm)
Operating Temperature Range	-40°C ~ 85°C
Efficiency	95%
Power (Watts) - Max	79.2W
Win Source Part Number	026944-PTH05020WAH
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Ultra Librarian 3D Model	Ultra Librarian PTH05020WAH CAD Model

Alternative Products

Description

The PTH05020WAH is a high-performance, 15-A rated, non-isolated power module developed by Texas Instruments.

Input Voltage Range: 4.5V to 5.5V
Output Voltage Range: 0.8V to 3.6V
Conversion Efficiency: Up to 95%
Auto-Track Sequencing: Yes
Over-Temperature Protection: Yes
Output Over-Current Protection: Yes
Under-Voltage Lockout: Yes
