PT6305N Real Image
Same model may have multiple batches, images only for reference.

PT6305N

Part No PT6305N
Manufacturer Texas Instruments
Catalog Power Supplies Board Mount DCDC Converters
Description REG ISR 3A 3.3V ADJ VRT TH 12SIP
Datasheet
PT6305N Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Power Supplies - Board Mount
Family DC DC Converters
Manufacturer Texas Instruments
Series PT6305
Packaging Tray
Type Non-Isolated PoL Module
Number of Outputs 1
Voltage - Input (Min) 4.5V
Voltage - Input (Max) 9V
Voltage - Output 1 3.3V
Current - Output (Max) 3A
Applications ITE (Commercial)
Mounting Style Through Hole
Package 12-SIP Module
Size / Dimension 2.06" L x 0.38" W x 0.67" H (52.3mm x 9.7mm x 17.0mm)
Operating Temperature Range 0°C ~ 70°C
Efficiency 80%
Power (Watts) - Max 9.9W
Win Source Part Number 026916-PT6305N
Popularity Medium
Supply and Demand Status Limited
Quantity per package 12
Ultra Librarian 3D Model Ultra Librarian PT6305N CAD Model

Description

The PT6305N is a high-performance, 3.3V, 30A, adjustable switching regulator module manufactured by Texas Instruments, a leading global semiconductor company.

  • Input Voltage Range: 4.5V to 5.5V
  • Output Voltage: Adjustable from 1.3V to 3.5V
  • Output Current Capacity: 30A
  • Efficiency: Up to 90%
