Same model may have multiple batches, images only for reference.

PGA204AU

Name: PGA204AU
Brand: Texas Instruments
SKU: 273608
Availability: InStock
Rating: 4.85 (48 reviews)

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	PGA204AU
Manufacturer	Texas Instruments
Catalog	Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description	IC OPAMP INSTR 1MHZ 16SOIC
Datasheet	PGA204AU Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Integrated Circuits
Manufacturer	Texas Instruments
Packaging	Tube/Rail
Status	Active
Amplifier Type	Instrumentation
Number of Circuits	1
Slew Rate	0.7 V/μs
-3db Bandwidth	1MHz
Current - Input Bias	500pA
Voltage - Input Offset	25μV
Operating Supply Current	5.2mA
Channel Output Current	23mA
Supply Voltage - Operating	9 V to 36 V, ±4.5 V to 18 V
Temperature Range - Operating	-40°C to 85°C
Mounting	SMD (SMT)
Case / Package	16-SOIC
Win Source Part Number	026681-PGA204AU
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Limited
Application Field	Used in Test & Measurement, Medical, Industrial
Family Name	PGA204
Introduction Date	April 01, 2006
ECCN	EAR99
Country of Origin	Taiwan
Halogen Free	Compliant
Estimated EOL Date	2028
Ultra Librarian 3D Model	Ultra Librarian PGA204AU CAD Model

Alternative Products

Description

The PGA204AU is a high-performance, microprocessor-compatible, programmable gain amplifier (PGA) from Texas Instruments.

Gain Range: 1 to 10,000
Offset Voltage: 500µV
Offset Drift: 2µV/°C
Noise Level: 25nV/√Hz @ 1kHz
Supply Range: ±2.25V to ±18V
Package: 16-pin SOIC
Overvoltage Protection: Up to ±40V
