Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Tube/Rail
Status Active
Number of Channels 1, UART
FIFO's 16 Byte
Data Rate (Max) 1.5Mbps
Supply Voltage - Operating 4.5 V to 5.5 V
With False Start Bit Detection Yes
With Modem Control Yes
Mounting SMD (SMT)
Case / Package 44-PLCC (16.58x16.58)
Win Source Part Number 082050-PC16550DV
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Application Field Used in Signal Processing
Ultra Librarian 3D Model Ultra Librarian PC16550DV CAD Model

Description

The PC16550DV is a high-performance, universal asynchronous receiver-transmitter (UART) with 16-byte FIFOs from Texas Instruments, a leading global semiconductor company.

  • Applications: telecommunications, data communications, and industrial equipment
  • Features: programmable baud rate generator
  • Channels: two independent DMA channels for transmit and receive operations
  • Features: 16-byte FIFOs for both transmit and receive
  • Voltage Range: 4.5 V to 5.5 V
  • Temperature Range: wide temperature range
  • Error Detection: parity error detection, framing error detection, and a break detection feature
