OPA2604AU/2K5E4 Real Image OPA2604AU/2K5E4 real image
Same model may have multiple batches, images only for reference.
OPA2604AU/2K5E4 Real Image OPA2604AU/2K5E4 real image
OPA2604AU/2K5E4 Real Image OPA2604AU/2K5E4 real image
Same model may have multiple batches, images only for reference.

OPA2604AU/2K5E4

Part No OPA2604AU/2K5E4
Manufacturer Texas Instruments
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description IC OPAMP GP 20MHZ 8SOIC
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Amplifier Type General Purpose
Number of Circuits 2
Slew Rate 25 V/μs
Gain Bandwidth Product (GBP) 20MHz
Current - Input Bias 100pA
Voltage - Input Offset 1mV
Operating Supply Current 10.5mA
Channel Output Current 35mA
Supply Voltage - Operating 9 V to 48 V, ±4.5 V to 24 V
Temperature Range - Operating -25°C to 85°C
Mounting SMD (SMT)
Case / Package 8-SOIC
Win Source Part Number 004229-OPA2604AU/2K5E4
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian OPA2604AU/2K5E4 CAD Model

Description

The OPA2604AU/2K5E4 is a high-performance, dual operational amplifier produced by Texas Instruments, a global semiconductor company that designs, manufactures, and sells analog and embedded processing chips.

  • Slew Rate: 25 V/µs
  • Gain Bandwidth Product: 20 MHz
  • Noise Density: 10 nV/√Hz @ 1 kHz
  • Total Harmonic Distortion (THD): 0.0003% @ 1 kHz
  • Supply Voltage Range: ±4.5 V to ±24 V
  • Quiescent Current: 4 mA per channel
  • Operating Temperature Range: -40°C to +85°C
  • Package: Compact, surface-mount SOIC
  • Power Supply Voltage: Fully specified
  • Differential Input Voltage Ranges: Fully specified
  • Output Short-Circuit Protection: Yes
