Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Transceiver
Protocol RS232
Number of Drivers/Receivers 2/2
Duplex Full
Receiver Hysteresis 300mV
Data Rate 250kbps
Supply Voltage - Operating 3 V to 5.5 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 20-SSOP
Win Source Part Number 021476-MAX3222IDBR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian MAX3222IDBR CAD Model

Description

The MAX3222IDBR is a next-generation product from Texas Instruments, a global leader in semiconductor technology.

  • Product: 2/2 transceiver
  • Operating Voltage: 3.0V to 5.5V
  • Standby Mode: Low-power
  • Receivers: 2
  • Drivers: 2
  • ESD Protection: ±15kV (all signal pins)
  • Slew Rate Limited: Yes
  • Package: 20-pin SSOP
