Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Transceiver
Protocol RS232
Number of Drivers/Receivers 1/1
Duplex Full
Receiver Hysteresis 500mV
Data Rate 250kbps
Supply Voltage - Operating 3 V to 5.5 V
Temperature Range - Operating 0°C to 70°C
Mounting SMD (SMT)
Case / Package 16-SSOP
Win Source Part Number 021459-MAX3221ECDBR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian MAX3221ECDBR CAD Model

Description

The MAX3221ECDBR is a highly advanced, high-performing, and efficient product from Texas Instruments, a globally renowned company with a reputation for precision and quality in the field of electronic components.

  • Type: Single driver, single receiver RS-232 interface device
  • Operating Voltage: 3.0V to 5.5V
  • Standby Mode: Less than 1µA
  • Data Rate: Up to 120kbps
  • Driver Output Slew Rate Control: 250kbps
  • ESD Protection: Exceeds ±15kV using the human body model (HBM)
  • Package: 16-pin SSOP (DB) package
  • Operating Temperature: -40°C to +85°C
