LMV824MX/NOPB

Part No LMV824MX/NOPB
Manufacturer Texas Instruments
Catalog Linear - Amplifiers - Instrumentation, OP Amps, Buffer Amps
Description IC OPAMP GP 5.6MHZ RRO 14SOIC
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Amplifier Type General Purpose
Number of Circuits 4
Output Type Rail-to-Rail
Slew Rate 2 V/μs
Gain Bandwidth Product (GBP) 5.6MHz
Current - Input Bias 100nA
Voltage - Input Offset 3.5mV
Operating Supply Current 1mA
Channel Output Current 45mA
Supply Voltage - Operating 2.5 V to 5.5 V, ±1.25 V to 2.75 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 14-SOIC
Win Source Part Number 019664-LMV824MX/NOPB
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name LMV824
Introduction Date August 01, 1999
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian LMV824MX/NOPB CAD Model

Description

The LMV824MX/NOPB is a high-quality, highly reliable and versatile integrated circuit (IC) product from Texas Instruments, a global leader in semiconductor technology. This product is part of Texas Instruments' LMV824 series, which includes a range of operational amplifiers (op-amps) that are designed for use in a wide variety of electronic devices and systems.

  • Supply Voltage Range: 2.7V to 5.5V (single or dual supply)
  • Number of Op-Amps: Quad
  • Package: 14-pin SOIC
  • Features: Rail-to-rail output swing, low input bias current, high slew rate of 1V/µs, low input noise voltage, low input offset voltage, temperature range -40°C to 125°C
  • Applications: Audio equipment, sensors, data acquisition systems, and communication devices

Its low power consumption, wide supply voltage range, high slew rate, and low input noise voltage make it a superior choice for designers looking for high-performance op-amps.
