Product Overview: LM336BMX-2.5 Voltage Reference

The LM336BMX-2.5 is a precision 2.5V shunt regulator diode designed by Texas Instruments to provide a stable reference voltage for various applications. This high-quality voltage reference is widely used in power supplies, digital voltmeters, and other equipment requiring an accurate voltage calibration.

Key Features

• Reference Voltage: 2.5V with an initial accuracy of 1%
• Temperature Coefficient: Typically 20 ppm/°C, ensuring minimal deviation over a wide temperature range
• Low Dynamic Impedance: Ensures stable reverse breakdown voltage under varying current conditions
• Wide Operating Current: Ranging from 400 µA to 10 mA, adaptable to diverse applications
• Package Type: Supplied in an easy-to-use surface-mount SOT-23 package

Applications

The LM336BMX-2.5 is suitable for a diverse set of applications, including but not limited to:

• Adjustable power supplies
• Analog-to-digital converters (ADCs)
• Digital-to-analog converters (DACs)
• Battery chargers
• Precision current limiters
• Instrumentation

Quality and Reliability

As with all Texas Instruments products, the LM336BMX-2.5 is manufactured to the highest quality standards, ensuring reliable performance in critical applications. It is designed to operate effectively over a wide industrial temperature range, maintaining its precision voltage reference under various environmental conditions.

Technical Specifications

For designers and engineers looking for a reliable voltage reference with stable characteristics, the LM336BMX-2.5 from Texas Instruments is an excellent choice that combines performance with versatility.
