ISO7420FEDR Real Image ISO7420FEDR real image584
Same model may have multiple batches, images only for reference.
ISO7420FEDR Real Image ISO7420FEDR real image584
ISO7420FEDR Real Image ISO7420FEDR real image584
Same model may have multiple batches, images only for reference.

ISO7420FEDR

Part No ISO7420FEDR
Manufacturer Texas Instruments
Catalog Digital Isolators
Description DGTL ISO 2.5KV GEN PURP 8SOIC / Digital Isolator Logic 2-CH 50Mbps 8-Pin SOIC T/R
Datasheet
ISO7420FEDR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Technology Capacitive Coupling
Type General Purpose
Isolated Power No
Number of Channels 2
Inputs - Side 1/Side 2 2/0
Channel Type Unidirectional
Isolation Voltage 2500Vrms
Common Mode Transient Immunity (Min) 25kV/μs
Data Rate 50Mbps
Propagation Delay tpLH / tpHL (Max) 11ns, 11ns
Pulse Width Distortion (Max) 3ns
Rise and Fall Time 1.8ns, 1.7ns
Supply Voltage - Operating 3 V to 5.5 V
Temperature Range - Operating -40°C to 125°C
Case / Package 8-SOIC
Win Source Part Number 002078-ISO7420FEDR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name ISO7420FE
Introduction Date January 01, 2011
ECCN EAR99
Country of Origin Taiwan
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian ISO7420FEDR CAD Model

Description

The ISO7420FEDR by Texas Instruments is a high-performance, advanced digital isolator product that is designed to provide efficient isolation in a wide range of applications.

  • Channels: Two isolated channels
  • Data Rates: Up to 1 Mbps
  • Isolation: Galvanic isolation of up to 2500 VRMS for 1 minute per UL1577
  • Power Consumption: Low
  • Supply Voltage Range: 3.0 to 5.5 V
  • Electromagnetic Compatibility (EMC): Excellent
  • Operating Temperature Range: -40°C to +125°C
  • Package: Compact 8-pin SOIC package
