ISO7321FCDR Real Image ISO7321FCDR Real Image1 ISO7321FCDR Real Image2
Same model may have multiple batches, images only for reference.
ISO7321FCDR Real Image ISO7321FCDR Real Image1 ISO7321FCDR Real Image2
ISO7321FCDR Real Image ISO7321FCDR Real Image1 ISO7321FCDR Real Image2
Same model may have multiple batches, images only for reference.

ISO7321FCDR

Part No ISO7321FCDR
Manufacturer Texas Instruments
Catalog Digital Isolators
Description DGTL ISO 3KV 2CH GEN PURP 8SOIC
Datasheet
ISO7321FCDR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Technology Capacitive Coupling
Type General Purpose
Isolated Power No
Number of Channels 2
Inputs - Side 1/Side 2 1/1
Channel Type Unidirectional
Isolation Voltage 3000Vrms
Common Mode Transient Immunity (Min) 25kV/μs
Data Rate 25Mbps
Propagation Delay tpLH / tpHL (Max) 57ns, 57ns
Pulse Width Distortion (Max) 4ns
Rise and Fall Time 2.4ns, 2.1ns
Supply Voltage - Operating 3 V to 5.5 V
Temperature Range - Operating -40°C to 125°C
Case / Package 8-SOIC
Win Source Part Number 002074-ISO7321FCDR
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian ISO7321FCDR CAD Model

Description

The ISO7321FCDR is a high-performance, dual-channel digital isolator product from Texas Instruments, a global leader in semiconductor technology.

  • Isolation Technology: Texas Instruments' innovative capacitive isolation technology
  • Isolation Barrier: Up to 2500 Vrms
  • Data Rate: Up to 25 Mbps
  • Channels: Two channels, one forward and one reverse
  • Supply Range: 2.7 V to 5.5 V
  • Package: Compact 8-pin SOIC package
  • Temperature Range: Extended industrial temperature range of -40°C to +125°C
  • Power Consumption: Low
  • EMC Performance: Robust electromagnetic compatibility (EMC) performance
