ISO7240MDW Real Image ISO7240MDW real image574
Same model may have multiple batches, images only for reference.
ISO7240MDW Real Image ISO7240MDW real image574
ISO7240MDW Real Image ISO7240MDW real image574
Same model may have multiple batches, images only for reference.

ISO7240MDW

Part No ISO7240MDW
Manufacturer Texas Instruments
Catalog Digital Isolators
Description DGTL ISO 2.5KV GEN PURP 16SOIC
Datasheet
ISO7240MDW Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Texas Instruments
Packaging Tube/Rail
Status Active
Technology Capacitive Coupling
Type General Purpose
Isolated Power No
Number of Channels 4
Inputs - Side 1/Side 2 4/0
Channel Type Unidirectional
Isolation Voltage 2500Vrms
Common Mode Transient Immunity (Min) 25kV/μs
Data Rate 150Mbps
Propagation Delay tpLH / tpHL (Max) 23ns, 23ns
Pulse Width Distortion (Max) 2ns
Rise and Fall Time 2ns, 2ns
Supply Voltage - Operating 3.15 V to 5.5 V
Temperature Range - Operating -40°C to 125°C
Case / Package 16-SOIC
Win Source Part Number 002062-ISO7240MDW
Popularity Medium
Supply and Demand Status Limited
Application Field Used in Computers & Computer Peripherals
Ultra Librarian 3D Model Ultra Librarian ISO7240MDW CAD Model

Description

The ISO7240MDW is a high-performance, quad-channel digital isolator produced by Texas Instruments, a renowned leader in the semiconductor industry.

  • Channels: Four independent isolation channels (two forward, two reverse)
  • Data Transmission Speed: Up to 150 Mbps
  • Isolation Rating: 2500 Vrms
  • Power Consumption: Low
  • Supply Voltage Range: 2.7 to 5.5 V
  • Supply Current: 1.8 mA per channel @ 1 Mbps
  • Fail-Safe Output: Yes
  • Package: 16-pin SOIC (Small Outline Integrated Circuit)
  • Temperature Range: -40 to +125 degrees Celsius
