Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Isolators
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Technology Capacitive Coupling
Type General Purpose
Isolated Power No
Number of Channels 4
Inputs - Side 1/Side 2 4/0
Channel Type Unidirectional
Isolation Voltage 2500Vrms
Common Mode Transient Immunity (Min) 25kV/μs
Data Rate 25Mbps
Propagation Delay tpLH / tpHL (Max) 42ns, 42ns
Pulse Width Distortion (Max) 2.5ns
Rise and Fall Time 2ns, 2ns
Supply Voltage - Operating 3.15 V to 5.5 V
Temperature Range - Operating -40°C to 125°C
Case / Package 16-SOIC
Win Source Part Number 087842-ISO7240CDW
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Industrial, Communications & Networking, Computers & Computer Peripherals
Ultra Librarian 3D Model Ultra Librarian ISO7240CDW CAD Model

Description

The ISO7240CDW is a high-performance, advanced digital isolator product from Texas Instruments, a renowned global semiconductor company known for their innovation and development of analog ICs and embedded processors.

  • Channels: Four independent isolation channels (two inputs, two outputs)
  • Data Rate: Up to 25 Mbps
  • Supply Voltage Range: 2.7 V to 5.5 V
  • Isolation Voltage: 2500 Vrms for 1 minute per UL 1577
  • Propagation Delay: Less than 50 ns
  • Operating Temperature Range: -40°C to +125°C
  • Package: Compact 16-pin SOIC (DW) package
