ISO7220ADR Texas Instruments
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Isolators
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Technology Capacitive Coupling
Type General Purpose
Isolated Power No
Number of Channels 2
Inputs - Side 1/Side 2 2/0
Channel Type Unidirectional
Isolation Voltage 2500Vrms
Common Mode Transient Immunity (Min) 25kV/μs
Data Rate 1Mbps
Propagation Delay tpLH / tpHL (Max) 475ns, 475ns
Pulse Width Distortion (Max) 14ns
Rise and Fall Time 1ns, 1ns
Supply Voltage - Operating 3 V to 5.5 V
Temperature Range - Operating -40°C to 125°C
Case / Package 8-SOIC
Win Source Part Number 018124-ISO7220ADR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Automation & Process Control, Sensing & Instrumentation, Motor Drive & Control, Industrial
Family Name ISO7220A
Introduction Date May 01, 2007
ECCN EAR99
Country of Origin Taiwan
Halogen Free Compliant
Estimated EOL Date 2031
Ultra Librarian 3D Model Ultra Librarian ISO7220ADR CAD Model

Description

The ISO7220ADR from Texas Instruments is a high-performance, dual-channel digital isolator.

  • Channels: Two isolated channels (unidirectional or bidirectional)
  • Isolation Voltage: Up to 2500 Vrms for 1 minute per UL 1577
  • Temperature Range: -40°C to +125°C
  • Supply Range: 2.7 V to 5.5 V
  • Package: 8-pin SOIC
