ISO721DR Real Image
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Isolators
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Technology Capacitive Coupling
Type General Purpose
Isolated Power No
Number of Channels 1
Inputs - Side 1/Side 2 1/0
Channel Type Unidirectional
Isolation Voltage 2500Vrms
Common Mode Transient Immunity (Min) 25kV/μs
Data Rate 100Mbps
Propagation Delay tpLH / tpHL (Max) 24ns, 24ns
Pulse Width Distortion (Max) 2ns
Rise and Fall Time 1ns, 1ns
Supply Voltage - Operating 3 V to 5.5 V
Temperature Range - Operating -40°C to 125°C
Case / Package 8-SOIC
Win Source Part Number 018122-ISO721DR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian ISO721DR CAD Model

Description

The ISO721DR is a high-performance, digital isolator product manufactured by Texas Instruments, a leading global semiconductor company that designs, manufactures and sells analog and embedded processing chips.

  • Channels: Single channel
  • Supply Range: 3.3V to 5.5V
  • Isolation Technology: Silicon dioxide (SiO2)
  • Data Rate: Up to 90 Mbps
  • Safety Standards: UL1577 and IEC 60950-1
  • Package: 8-pin SOIC
