ISO721D Real Image ISO721D real image556 ISO721D Real Image
Same model may have multiple batches, images only for reference.
ISO721D Real Image ISO721D real image556 ISO721D Real Image
ISO721D Real Image ISO721D real image556 ISO721D Real Image
Same model may have multiple batches, images only for reference.

ISO721D

Part No ISO721D
Manufacturer Texas Instruments
Catalog Digital Isolators
Description DGTL ISO 4KV 1CH GEN PURP 8SOIC
Datasheet
ISO721D Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Isolators
Manufacturer Texas Instruments
Packaging Tube/Rail
Status Active
Technology Capacitive Coupling
Type General Purpose
Isolated Power No
Number of Channels 1
Inputs - Side 1/Side 2 1/0
Channel Type Unidirectional
Isolation Voltage 2500Vrms
Common Mode Transient Immunity (Min) 25kV/μs
Data Rate 100Mbps
Propagation Delay tpLH / tpHL (Max) 24ns, 24ns
Pulse Width Distortion (Max) 2ns
Rise and Fall Time 1ns, 1ns
Supply Voltage - Operating 3 V to 5.5 V
Temperature Range - Operating -40°C to 125°C
Case / Package 8-SOIC
Win Source Part Number 018121-ISO721D
Family Name ISO721
Introduction Date January 18, 2006
ECCN EAR99
Country of Origin Taiwan
Halogen Free Compliant
Estimated EOL Date 2027
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian ISO721D CAD Model

Description

The ISO721D is a high-performance, digital isolator product from Texas Instruments, a global semiconductor company that designs, manufactures, tests, and sells analog and embedded processing chips.

  • Data Rate: Up to 1 Mbps
  • Isolation: Up to 2500 Vrms per minute
  • Power Supply: 3.3V or 5V
  • Package: 8-pin SOIC
  • Compliance: UL1577 and IEC60747-5-2 (VDE0884, Rev 2)
