INA230AIRGTR Real Image INA230AIRGTR real image160 INA230AIRGTR real image161 INA230AIRGTR Real Image1 INA230AIRGTR Real Image2
Same model may have multiple batches, images only for reference.
INA230AIRGTR Real Image INA230AIRGTR real image160 INA230AIRGTR real image161 INA230AIRGTR Real Image1 INA230AIRGTR Real Image2
INA230AIRGTR Real Image INA230AIRGTR real image160 INA230AIRGTR real image161 INA230AIRGTR Real Image1 INA230AIRGTR Real Image2
Same model may have multiple batches, images only for reference.

INA230AIRGTR

Part No INA230AIRGTR
Manufacturer Texas Instruments
Catalog PMIC - Current Regulation/Management
Description IC CURRENT SHUNT MONITOR 16QFN
Datasheet
INA230AIRGTR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Purpose Current Monitor
Sensing Method High/Low-Side
Accuracy 0.5%
Voltage - Input 0 V to 28 V
Temperature Range - Operating -40°C to 125°C
Mounting SMD (SMT)
Case / Package 16-QFN (3x3)
Win Source Part Number 017298-INA230AIRGTR
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian INA230AIRGTR CAD Model

Description

The INA230AIRGTR is an advanced, high-performance product from the globally recognized semiconductor manufacturer, Texas Instruments.

  • Features: Programmable calibration value, alerting function, and configurable averaging
  • Feature: Calculate the power supply and making readings available to the user through the I2C interface
  • Operating Voltage: From a single supply ranging from 2.7V to 5.5V
  • Offset Voltage: 15uV (Max)
  • Gain Error: 0.2% (Max)
  • Package: Integrated 16-pin QFN
  • Temperature Range: -40°C to +125°C
  • Feature: Programmable conversion time
