Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Tube/Rail
Status Active
Type Transceiver
Protocol RS422, RS485
Number of Drivers/Receivers 2/2
Duplex Full
Receiver Hysteresis 70mV
Supply Voltage - Operating 4.5 V to 5.5 V
Temperature Range - Operating 0°C to 70°C
Mounting SMD (SMT)
Case / Package 16-SOIC
Win Source Part Number 080759-DS8922AM
Family Name DS8922A
Introduction Date February 01, 1997
ECCN EAR99
Country of Origin Malaysia
Halogen Free Not Compliant
Estimated EOL Date Obsolete
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Application Field Used in Industrial
Quantity per package 48
Ultra Librarian 3D Model Ultra Librarian DS8922AM CAD Model

Description

Product Overview

The DS8922AM is a high-performance transceiver tailored for differential signaling over EIA-485/422 twisted pair networks. Designed to manage data transfer efficiently, it is ideal for systems requiring reliable communication over long distances.

Features and Benefits

  • Supports data rates up to 30 Mbps
  • Enhanced receiver features for reduced signal distortion
  • Improved fault tolerance and protection features
  • Extended temperature operation for broader application usability

Applications

  • Remote communication systems
  • Building automation
  • Long-distance data transmission links
  • Industrial process controls
