DS34LV86TMX/NOPB Real Image DS34LV86TMX/NOPB Real Image
Same model may have multiple batches, images only for reference.
DS34LV86TMX/NOPB Real Image DS34LV86TMX/NOPB Real Image
DS34LV86TMX/NOPB Real Image DS34LV86TMX/NOPB Real Image
Same model may have multiple batches, images only for reference.

DS34LV86TMX/NOPB

Part No DS34LV86TMX/NOPB
Manufacturer Texas Instruments
Catalog Interface - Drivers, Receivers, Transceivers
Description IC LINE RVR QUAD CMOS DIF 16SOIC
Datasheet
DS34LV86TMX/NOPB Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Reel - TR
Status Active
Type Receiver
Protocol RS422, RS485
Number of Drivers/Receivers 0/4
Receiver Hysteresis 35mV
Supply Voltage - Operating 3 V to 3.6 V
Temperature Range - Operating -40°C to 85°C
Mounting SMD (SMT)
Case / Package 16-SOIC
Win Source Part Number 139572-DS34LV86TMX/NOPB
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian DS34LV86TMX/NOPB CAD Model

Description

DS34LV86TMX/NOPB

The DS34LV86TMX/NOPB is the lead-free version of the DS34LV86TMX, catering to applications with environmental and safety regulations while providing efficient and high-speed data performance.

  • Applications:
    • Automated test equipment
    • Medical diagnostics equipment
    • Secure data transmission networks
  • Features and Benefits:
    • Eco-friendly lead-free design for reduced environmental impact
    • Maintains high-speed and stability in data transmission
    • Wide supply voltage range for versatile application use
  • Additional Details:
    • Compliant with global environmental regulations
    • Proven performance in rigorous testing environments
