The DRV5011ADYBHR is a versatile and efficient Hall effect sensor designed by Texas Instruments, tailored for cost-sensitive and space-constrained applications. This magnetic sensor device offers a digital latch output and is part of TI's renowned DRV5011 series, known for their reliability and performance.

Key Features

• Bipolar Latching Operation: The sensor provides a latching digital output that changes state in the presence of south or north magnetic poles, making it ideal for position sensing and rotation detection.
• Wide Supply Voltage Range: It operates over a broad supply voltage range from 2.5V to 38V, accommodating various application requirements and simplifying integration into different system designs.
• Low Power Consumption: Designed for energy efficiency, the DRV5011ADYBHR has a low average current consumption, which is crucial for battery-powered and portable applications.
• High Temperature Performance: The sensor can operate in a wide temperature range from -40°C to +125°C, ensuring reliable performance in harsh environmental conditions.
• Chopper-Stabilized Design: This feature minimizes the influence of temperature and stress on the sensor's magnetic thresholds, enhancing accuracy and stability over time.

Applications

The DRV5011ADYBHR is adept at serving a multitude of industries and applications. Its compact size and precision make it an excellent choice for:

• Brushless DC (BLDC) motor commutation
• Position and speed sensing
• Proximity detection
• Tamper detection for utility meters
• Flow meters

Package and Availability

The device comes in a small, leaded SOT-23 package that is RoHS compliant and suitable for automated assembly processes. Its robust design ensures a long operational life, and it is available for purchase through Texas Instruments and authorized distributors.

For engineers and designers looking for a reliable and precise magnetic sensing solution, the DRV5011ADYBHR from Texas Instruments offers the perfect blend of performance, durability, and affordability.
