DCR010503U/1K Real Image DCR010503U/1K Real Image
Same model may have multiple batches, images only for reference.
DCR010503U/1K Real Image DCR010503U/1K Real Image
DCR010503U/1K Real Image DCR010503U/1K Real Image
Same model may have multiple batches, images only for reference.

DCR010503U/1K

Part No DCR010503U/1K
Manufacturer Texas Instruments
Catalog Power Supplies Board Mount DCDC Converters
Description IC REG ISOLATED 3.3V 0.3A 12SOP
Datasheet
DCR010503U/1K Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Power Supplies - Board Mount
Family DC DC Converters
Manufacturer Texas Instruments
Series DCR01
Packaging Reel(TR)
Type Isolated Module
Number of Outputs 1
Voltage - Input (Min) 4.5V
Voltage - Input (Max) 5.5V
Voltage - Output 1 3.3V
Current - Output (Max) 300mA
Power (Watts) - Manufacture Series 1W
Voltage - Isolation 1kV (1000V)
Applications ITE (Commercial)
Features Remote On/Off, OTP, SCP
Mounting Style SMD/SMT
Package 28-SOIC (0.295", 7.50mm Width) 12 Leads
Size / Dimension 0.70" L x 0.41" W x 0.10" H (17.9mm x 10.3mm x 2.5mm)
Operating Temperature Range -40°C ~ 85°C
Power (Watts) - Max 1W
Win Source Part Number 013875-DCR010503U/1K
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian DCR010503U/1K CAD Model

Description

DCR010503U/1K - Isolated DC-DC Converter

The DCR010503U/1K is a high-performance isolated DC-DC converter, offering a reliable solution for power supply designs requiring electrical isolation and efficient voltage transformation. With its robust design, it caters to a variety of applications needing consistent power integration.

  • Voltage Input/Output: 5V/3.3V
  • Power Output: 1W
  • Isolation Voltage: 1500V

Features and Benefits:

  • Compact size for space-constrained applications
  • High efficiency for reduced energy consumption
  • Enhanced electrical isolation for safety regulation compliance
  • Temperature range accommodating various environmental conditions

Applications:

  • Industrial control systems
  • Telecommunication equipment
  • Data communication devices
  • Input/output isolation for embedded systems
