CSD86330Q3D

Get a Quote

This model is a standard, industry-grade component frequently used in electronic manufacturing.

Part No	CSD86330Q3D
Manufacturer	Texas Instruments
Catalog	FETs - Arrays
Description	MOSFET 2N-CH 25V 20A 8SON
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Manufacturer	Texas Instruments
Standard Package	1
Category	Discrete Semiconductor Products
Family	FETs - Arrays
Series	NexFET
Packaging	Reel
FET Type	2 N-Channel (Half Bridge)
FET Feature	Logic Level Gate
Drain to Source Voltage (Vdss)	25V
Current - Continuous Drain (Id) @ 25°C	20A
Rds On (Max) @ Id Vgs	9.6 mOhm @ 14A 8V
Vgs(th) (Max) @ Id	2.1V @ 250µA
Gate Charge (Qg) @ Vgs	6.2nC @ 4.5V
Input Capacitance (Ciss) @ Vds	920pF @ 12.5V
Power - Max	6W
Operating Temperature Range	-55°C ~ 150°C (TJ)
Mounting Style	SMD/SMT
Package	8-PowerLDFN
Manufacturer Device Package	8-LSON (5x6)
Catalog	N-Channel Logic Level Gate FETs
Win Source Part Number	083179-CSD86330Q3D
Family Name	CSD86330Q3D
Introduction Date	October 01, 2010
ECCN	EAR99
Country of Origin	Philippines
Halogen Free	Not Compliant
Estimated EOL Date	2027
Is this a common-used part?	Yes
Popularity	High
Supply and Demand Status	Balance
Application Field	Used in Embedded Design & Development, Power Management
Estimated EOL Date	2028
Ultra Librarian 3D Model	Ultra Librarian CSD86330Q3D CAD Model

Description

The CSD86330Q3D delivers optimal power density and efficiency, making it a top choice for compact and high-powered applications.

Features and Benefits

Dual N-channel configuration for balanced performance
High-frequency operation for efficient switching
Strong thermal management for reliable long-term operation
Compact QFN package for space savings

Applications

VRM/VRD designs
UPS systems
Motor drives
Renewable energy systems

The CSD86330Q3D ensures robust performance and efficient power delivery in electronics requiring compact and powerful components.
