Product Overview: CD74HC4316PW from Texas Instruments

The CD74HC4316PW is a high-speed CMOS logic Quad Analog Switch/Multiplexer/Demultiplexer designed and manufactured by Texas Instruments, a leader in semiconductor innovation. This integrated circuit is engineered to handle digital and analog signals, making it a versatile choice for a wide range of applications in various industries.

Key Features

• Wide Operating Voltage Range: The device operates with a supply voltage range of 2V to 6V, accommodating various logic levels and providing designers with flexibility in system design.
• Low ON Resistance: Characterized by a low ON resistance (typically 35 ohms at 4.5V), the CD74HC4316PW ensures minimal signal attenuation when the switch is in the ON state, which is crucial for maintaining signal integrity.
• High Noise Immunity: With a noise immunity characteristic of a fully CMOS device, the switch provides stable performance in electrically noisy environments.
• Low Power Consumption: The device features a low power consumption profile, which is essential for battery-operated and power-sensitive applications.
• Fast Switching Speed: The CD74HC4316PW boasts fast switching times, with a typical propagation delay time of only 16ns at VCC = 5V, ensuring quick response in high-speed systems.

Applications

The CD74HC4316PW is suitable for a variety of applications, including:

• Analog multiplexing and demultiplexing
• Signal gating
• Chopper circuits
• Modem – transmit/receive switching
• Sample and hold circuits
• Digital signal processing (DSP)

Product Specifications

The CD74HC4316PW is offered in a TSSOP (Thin Shrink Small Outline Package) with 16 pins, providing a compact footprint for space-constrained applications. The device features four independently selectable switches, which can be controlled by digital inputs. It is characterized for operation from -55°C to 125°C, ensuring reliable performance across a wide temperature range.

Quality and Reliability

As with all Texas Instruments products, the CD74HC4316PW is manufactured to the highest quality standards, ensuring reliability and performance consistency. It is a testament to Texas Instruments' commitment to providing industry-leading solutions for electronic systems.
