Product Overview: CD74HC14PW from Texas Instruments

The CD74HC14PW is a high-speed CMOS Logic Hex Schmitt-Trigger Inverter manufactured by Texas Instruments. This integrated circuit is designed to provide robust noise immunity and stable performance across a wide range of operating conditions. The device features six independent inverters with Schmitt-Trigger inputs, making it an ideal choice for applications requiring pulse shaping, signal conditioning, or where slow input transitions are present.

Key Features

• Logic Type: Hex Schmitt-Trigger Inverter
• Package / Case: TSSOP-14
• Operating Temperature: -55°C to +125°C
• Supply Voltage Range: 2V to 6V
• Logic Family: HC
• Propagation Delay Time: 13ns at 4.5V
• Output Current: ±5.2mA
• Mounting Type: Surface Mount

Applications

The CD74HC14PW is versatile and can be used in various applications, including:

• Waveform generation
• Signal processing
• Communication systems
• Embedded systems
• Logic circuitry

Performance and Quality

Texas Instruments is known for its commitment to quality and reliability, and the CD74HC14PW is no exception. It is characterized for operation from -55°C to +125°C, ensuring performance in extreme conditions. The device also offers balanced propagation delays and low power consumption, which is critical for power-sensitive applications.

Environmental Compliance

The CD74HC14PW is RoHS compliant, meaning it adheres to the European Union's directive on the restriction of hazardous substances in electronic equipment. This compliance ensures that the product is environmentally friendly and reduces the ecological impact.

Ordering Information

When ordering the CD74HC14PW, it is important to refer to the complete part number including the suffix to specify the package type. For example, the TSSOP-14 package is indicated by the 'PW' suffix in the part number. For detailed information on ordering and shipping, please consult Texas Instruments' official website or authorized distributors.
