Products specifications

Categories Integrated Circuits
Manufacturer Texas Instruments
Packaging Tape and Reel
Resolution 16
Sampling Rate (Per Second) 500k
Number of Inputs 4
Input Type Pseudo-Differential, Single Ended
Data Interface SPI
Configuration MUX-S/H-ADC
Number of A/D Converters 1
Architecture SAR
Reference Type External
Supply Voltage , Analog 2.7V ~ 3.6V, 5V
Supply Voltage , Digital 1.65V ~ 5.5V
Temperature Range - Operating -40°C ~ 85°C
Manufacturer Package 24-TSSOP
Supplier Device Package 24-TSSOP
Mounting Style SMD
Family Part Number ADS8331
Manufacturer Pack Quantity 2,000
MSL Level 2 (1 Year)
Win Source Part Number 1142026-ADS8331IBPWR
Manufacturer Homepage www.ti.com
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian ADS8331IBPWR CAD Model

Description

The Texas Instruments ADS8331IBPWR is a high-precision, 16-bit analog-to-digital converter (ADC) that offers a seamless blend of performance and power efficiency, making it an ideal choice for a wide range of applications, including medical instrumentation, industrial process control, and battery-powered devices.

This ADC operates on a single 2.7V to 5.5V power supply and features a serial peripheral interface (SPI) compatible with 1.8V, 3V, or 5V logic, providing versatility for various microcontroller interfaces. The ADS8331IBPWR is a member of the microPower™ family, boasting a low-power consumption of just 0.75mW at a 100kHz sample rate, which significantly reduces the power requirements for continuous data acquisition systems.

The device incorporates a 2-channel multiplexer with a channel sequencer, allowing for simplified monitoring of two different input signals. The ADS8331IBPWR also features an internal 2.048V reference, which eliminates the need for external components and simplifies design. For applications requiring higher precision, an external reference can also be used.

With its impressive signal-to-noise ratio (SNR) and low distortion characteristics, the ADS8331IBPWR ensures accurate signal conversion, critical for high-end precision applications. Its programmable data rate supports up to 250k samples per second (SPS), providing the flexibility to cater to both high-speed and low-speed system requirements.

Enclosed in a compact TSSOP-16 package, the ADS8331IBPWR is designed to occupy minimal board space, which is essential for space-constrained applications. Texas Instruments' commitment to quality and reliability is evident in the ADS8331IBPWR's design and manufacturing, ensuring that it meets the stringent requirements of industrial and commercial applications.

In summary, the ADS8331IBPWR from Texas Instruments is a robust, high-performance ADC solution that offers designers a balance of speed, precision, and power efficiency, enabling the development of sophisticated and reliable systems across various industries.
