Same model may have multiple batches, images only for reference.
T73S5D15-05 Real Image
Same model may have multiple batches, images only for reference.

T73S5D15-05

Part No T73S5D15-05
Manufacturer TE Connectivity
Catalog Power Relays, Over 2 Amps
Description Relay Power Over 2A / RELAY GEN PURPOSE SPDT 10A 5V
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Relays
Manufacturer TE Connectivity Potter & Brumfield Relays
Packaging Tube/Rail
Status Obsolete(EOL)
Relay Type General Purpose
Coil Type Non Latching
Coil Current 89mA
Coil Voltage 5VDC
Contact Form SPDT (1 Form C)
Contact Rating (Current) 10A
Switching Voltage 120VAC, 28VDC - Max
Turn On Voltage (Max) 3.25 VDC
Turn Off Voltage (Min) 0.25 VDC
Operate Time 10ms
Release Time 5ms
Features Insulation - Class F, Sealed - Fully
Mounting Through Hole
Termination Style PC Pin
Coil Power 450 mW
Coil Resistance 55.5 Ohms
Temperature Range - Operating -30°C to 80°C
Win Source Part Number 047691-T73S5D15-05
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name T73
Introduction Date June 02, 2003
ECCN EAR99
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian T73S5D15-05 CAD Model

Description

The TE Connectivity Potter & Brumfield Relays is a high-quality electronic component that is widely used in various electronic circuits.

  • Win Source Part Number: 047691-T73S5D15-05
  • Category: Relays
  • Supply and Demand Status: Limited.
  • Insulation: Class F
  • Sealed: Fully
  • Contact Form: SPDT (1 Form C)
  • Mounting: Through-Hole
  • Coil Resistance: 55.5 Ohms
  • Coil Current: 89mA
  • Coil Voltage: 5VDC
  • Contact Rating: 10A
  • Switching Voltage: 120VAC, 28VDC - Max
  • Turn-On Voltage (Max): 3.25 VDC
  • Turn-Off Voltage (Min): 0.25 VDC
  • Release Time: 5ms
  • Coil Power: 450 mW
  • Description: This relay is a great choice for those who are looking for a high-quality electronic component that can deliver exceptional results.
