Products specifications Report Issue?

Category Resistors - Through Hole Resistors
Mfr TE Connectivity Passive Product
Series CFR25, Neohm
Product Status Active
Resistance 47 Ohms
Tolerance ±5%
Power (Watts) 0.333W, 1/3W
Composition Carbon Film
Features -
Temperature Coefficient 0/ -450ppm/°C
Temperature Range - Operating -55°C ~ 155°C
Package / Case Axial
Supplier Device Package Axial
Size / Dimension 0.098" Dia x 0.268" L (2.50mm x 6.80mm)
Height - Seated (Max) -
Number of Terminations 2
Failure Rate -
Base Product Number CFR25
MSL Level Not Applicable
REACH Status Vendor Undefined
ECCN EAR99
HTSUS 8533.10.0065
Win Source Part Number 1374825-CFR25J47R
Ultra Librarian 3D Model Ultra Librarian CFR25J47R CAD Model

Description

The TE Connectivity Passive Product CFR25, Neohm series provides high-quality through hole resistors for your electronic circuits. TE Connectivity Passive Product CFR25, Neohm series is the product and TE Connectivity is the manufacturer.

  • Package/Case: Axial
  • Size/Dimension: 0.098" Dia x 0.268" L (2.50mm x 6.80mm)
  • Resistance: 47 Ohms
  • Power Rating: 0.333W (1/3W)
  • Composition: Carbon Film
  • Tolerance: ±5%
  • Number of Terminations: 2
  • Status: Active
