ANT-916-HESM TE Connectivity – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

ANT-916-HESM

Part No ANT-916-HESM
Manufacturer TE Connectivity
Catalog RF Antennas
Description RF ANT 916MHZ HELICAL SM
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

RF Family/Standard General ISM
Frequency Group UHF (300MHz ~ 1GHz)
Frequency (Center/Band) 915MHz
Frequency Range 865MHz ~ 965MHz
Antenna Type Helical
Number of Bands 1
VSWR 2
Gain 2.4dBi
Termination Solder
Mounting Type Surface Mount
Height (Max) 0.350" (8.90mm)
Applications ISM, LoRa, Sensor Networks, SigFox
Package Bag
Supply and Demand Status Normal
Win Source Part Number 1510824-ANT-916-HESM
Ultra Librarian 3D Model Ultra Librarian ANT-916-HESM CAD Model
