767054-1

Name: 767054-1
Brand: TE Connectivity
SKU: 1332098
Availability: InStock
Rating: 4.84 (5 reviews)

Get a Quote

Part No	767054-1
Manufacturer	TE Connectivity
Catalog	Rectangular Connectors
Description	CONN RCPT 38P SMD PALLAD-NICKEL / 38 Position Connector Receptacle, Center Strip Contacts Surface Mount Palladium-Nickel
Sample
Rohs State	Need to verify
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Category	Connectors, Interconnects>Rectangular Connectors>Arrays, Edge Type, Mezzanine (Board to Board)
Manufacturer	TE Connectivity AMP Connectors
Packaging	Tube
Connector Type	Receptacle, Center Strip Contacts
Number of Positions	38
Pitch	0.025" (0.64mm)
Number of Rows	2
Mounting	Surface Mount
Features	Board Guide, Ground Bus (Plane)
Contact Finish	Palladium-Nickel
Contact Finish Thickness	5.00µin (0.127µm)
Mated Stacking Heights	6.6mm, 9mm, 10.92mm, 12.57mm, 17.96mm, 18.75mm, 20mm, 22.86mm
Height Above Board	0.236" (6.00mm)
Base Product Number	767054
RoHS Status	RoHS non-compliant
MSL Level	1 (Unlimited)
REACH Status	REACH Affected
ECCN	EAR99
HTSUS	8536.69.4040
Other Part Number	767054-1-ND,2266-767054-1,A121641
Standard Package	21
Win Source Part Number	1332098-767054-1
Ultra Librarian 3D Model	Ultra Librarian 767054-1 CAD Model

Description

The TE Connectivity AMP Connectors 1332098-767054-1 is a rectangular connector that is categorized as an array, edge type, mezzanine (board to board) connector.

Pitch: 0.025" (0.64mm)
Number of Positions: 38
Connector Type: Receptacle, Center Strip Contacts
Height Above Board: 0.236" (6.00mm)
Contact Finish: Palladium-Nickel
Mated Stacking Heights: 6.6mm, 9mm, 10.92mm, 12.57mm, 17.96mm, 18.75mm, 20mm, and 22.86mm
