749069-9 Real Image
Same model may have multiple batches, images only for reference.

749069-9

Part No 749069-9
Manufacturer TE Connectivity
Catalog D - Sub Connectors
Description CONN D-TYPE RCPT 100P VERT SLDR  /  100 Position D-Type Receptacle, Female Sockets Connector
Sample
Rohs State Need to verify
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects>D-Sub Connectors
Mfr TE Connectivity AMP Connectors
Series AMPLIMITE .050 III
Package Tube
Connector Style D-Type
Connector Type Receptacle, Female Sockets
Number of Positions 100
Number of Rows 2
Mounting Type Through Hole
Shell Size, Connector Layout 0.050 Pitch x 0.100 Row to Row
Contact Type Signal
Flange Feature Housing/Shell (2-56); Latchblocks, Rails
Termination Solder
Shell Material, Finish Steel, Nickel Plated
Contact Finish Gold
Material Flammability Rating UL94 V-0
Current Rating (Amps) 1A
Features Shielded
Voltage Rating 30V
Color Black
Dielectric Material Thermoplastic
Contact Material Phosphor Bronze
Temperature Range - Operating -55°C ~ 105°C
Base Product Number 749069
RoHS Status RoHS non-compliant
MSL Level 1 (Unlimited)
REACH Status REACH Affected
ECCN EAR99
HTSUS 8536.69.4040
Other Names 2266-749069-9,-749069-9-SI,A23759,749069-9-ND,7490699
Standard Package 378
Win Source Part Number 1028799-749069-9
Ultra Librarian 3D Model Ultra Librarian 749069-9 CAD Model

Description

This D-sub connector is part of the AMPLIMITE .050 III series and has 100 positions.

  • Positions: 100
  • Shielded: Yes
  • Color: Black
  • Connector: Receptacle with female sockets
  • Rows: 2
  • Termination: Solder
  • Contact Finish: Gold
  • Shell Material: Steel with nickel-plated finish
  • Voltage Rating: 30V
  • Temperature Range: -55°C ~ 105°C
  • Flammability Rating: UL94 V-0
  • Standard Package: 378
