Products specifications

Categories Connectors
Estimated Pruduction Lead Time 3 Weeks
Features Jack Modular Connector 8p8c (RJ45, Ethernet) 90° Angle (Right) Unshielded Cat3
Manufacturer TE Connectivity
Package Tray
Operating Temperature Range -40°C ~ 85°C
Mounting Through Hole
Family Name 5555164
MSL Level 1 (Unlimited)
REACH Status Vendor Undefined
ECCN EAR99
HTSUS 8536.69.4040
Other Part Number A31442, -5555164-1-SI, -2-42938-4632-SI-ND, -2-42938-4632-SI, 55551641
Quantity per package 152
Popularity High
Supply and Demand Status Balance
Win Source Part Number 907451-5555164-1
Ultra Librarian 3D Model Ultra Librarian 5555164-1 CAD Model

Description

Product Description for 5555164-1 from TE Connectivity

The 5555164-1 from TE Connectivity is a single-port, right-angle, unshielded RJ45 jack connector. It is designed for PCB mounting and has a solder termination. The connector has eight positions and eight contacts, and is rated for Category 3 performance.

The 5555164-1 is made with high-quality materials and construction, and is designed to withstand the rigors of everyday use. It has a durable PBT housing and gold-plated contacts for excellent signal integrity and corrosion resistance. The connector also has a board lock to ensure a secure connection to the PCB.

The 5555164-1 is a versatile connector that can be used in a variety of applications, including:

Ethernet networks Industrial control systems Medical devices Consumer electronics Telecommunications equipment The 5555164-1 is easy to install and use. It comes with a comprehensive datasheet that includes detailed installation instructions and specifications.

Features and Benefits of the 5555164-1

Single-port, right-angle, unshielded RJ45 jack connector PCB mounting with solder termination Eight positions and eight contacts Category 3 performance Durable PBT housing and gold-plated contacts Board lock for a secure connection Versatile connector for a variety of applications Easy to install and use Applications for the 5555164-1

Ethernet networks Industrial control systems Medical devices Consumer electronics Telecommunications equipment Conclusion

The 5555164-1 from TE Connectivity is a high-quality, reliable RJ45 jack connector that is ideal for a variety of applications. It is easy to install and use, and comes with a comprehensive datasheet for detailed information.
